Allocating Inactive End Regions Within Installed Travel

System boundary

A resistive card, wiper footprint, carrier, linkage, housing stops and receiving electronics across the defined installed travel. The review allocates regions and observable outputs; machine or vehicle safety, stop strength and diagnostic response remain integrator responsibilities.

Name five regions at each travel end

Define hard-stop approach, permitted mechanical overtravel, electrically continuous transition, calibrated measurement span and forbidden contact area. These regions may overlap differently at the two ends and under opposite travel direction. Show them on one position axis referenced to a physical datum. State whether the output should clamp, continue monotonically, become diagnostic or remain unspecified outside the calibrated span. This terminology prevents a mechanical clearance from being confused with an electrical accuracy requirement.

Use the entire wiper footprint in boundary placement

The electrical event begins when the leading part of the contact footprint reaches a feature, not when its nominal center arrives. Include footprint length, skew, wear width and carrier rotation. A bridged contact may touch two segments simultaneously. The usable endpoint must account for the adverse footprint edge plus track registration. Preserve contact force and support conditions because rocking or bounce can change which portion carries current.

Calculate remaining endpoint margin in one coordinate system

For one direction, subtract adverse stop, linkage, wiper and printed-boundary errors from the nominal separation.

Work an illustrative endpoint allocation

Assume a nominal 2.20 mm separation from stop position to calibrated-track start. Reserve 0.50 mm for contact half-footprint and skew, 0.35 mm for mechanism variation, 0.20 mm for printed registration and 0.40 mm for an electrically continuous transition. The remaining margin is 0.75 mm. These example values only show accounting. Actual allowances come from the installed mechanism, drawing and validation evidence, and the opposite endpoint requires its own calculation.

Observe reversal, rebound and approach speed

Static fixture positions do not reveal stop impact, spring relaxation or backlash take-up. Record position reference and output during slow approach, normal-speed approach, stop contact and reversal. Repeated crossings can create apparent dropouts that a controller filter either exposes or hides. The test should distinguish true loss of contact from acquisition timing. Never use digital filtering to justify a geometry that violates the agreed continuous-contact boundary.

Assign every endpoint statement to an owner

A compact allocation table keeps drawing requirements and controller behavior aligned.

Interpret endpoint symptoms without guessing

A repeatable offset at one end may indicate datum or stop position. Direction-dependent onset suggests backlash or footprint asymmetry. Speed-dependent dropout points to bounce or sampling interaction. A gradual curve departure can arise from track transition geometry or input loading. Preserve raw position and voltage records before recalibration. Re-zeroing the system can conceal a boundary shift while leaving the physical contact risk unchanged.

Validate tolerance corners and both directions

Test representative low and high stop locations, card registration, wiper reach, temperature states and assembly orientations. Sweep from both directions at defined rates, dwell at endpoints and repeat reversals. Inspect contact marks after testing. The integrator defines diagnostic and safe-response acceptance; card evidence alone cannot qualify those functions. ChipSimple can manufacture and inspect drawing-defined features subject to review, while installed travel remains customer-owned.

Release an endpoint map that survives revision

The controlled output shows datums, nominal positions, tolerance contributors, active-span bounds, transition behavior and responsibility for controller interpretation. Link it to card, housing, linkage and software revisions. Reopen allocation after changes to stops, springs, pivots, track artwork, wiper, mounting, temperature range, supply or filtering. A single total dead-zone number is not enough to manage these distinct interfaces.

Endpoint calibration should retain raw contact position independently from the commanded or indicated position. A mechanism can reach a physical stop while an elastic member continues to deflect, or a controller can saturate its reported value before the contact reaches the transition zone. Use a direct reference appropriate to the mechanism during validation and time-align it with electrical output. Inspect witness marks to confirm where the wiper actually traveled. If the system permits occasional overtravel during assembly or service, evaluate that state separately from normal operation. Release documentation should state whether return from the extreme must be monotonic and how many samples may be invalid under the integrator-approved diagnostic policy.

When wear is relevant, verify endpoint allocation after the agreed cycling exposure as well as before it. Contact footprint can broaden, springs can relax and stops can settle, changing the available margin. Compare endpoint onset, hysteresis and witness marks on the same identified assemblies. Any recalibration performed during the test must remain visible in the record because it changes the observed electrical boundary.
